Nap-Gard®

FBE Powder Coatings


Nap-Gard® was developed to provide maximum corrosion protection of internal and external pipe for oil and gas pipelines as well as valve and girth weld coating protection. Axalta Nap-Gard® fusion bonded epoxy powder coatings are the innovator behind today’s pipe coating practices using epoxy coatings.

Available in single, dual and multi-layer systems, Nap-Gard® is designed to provide maximum corrosion protection of internal and external pipe for oil and gas pipelines along with demanding wastewater and saltwater environments.

Nap-Gard® also provides corrosion protection for:



Nap-Gard® External Pipe Coatings

Single Layer Systems

7-2500 Series – In buried service, the coating is designed to be capable of withstanding continuous operating temperatures of 107°C (225°F). May also be used on the inside of steel pipe and fittings, and is NSF-61 approved for potable water services.

7-2514 EN Series – Designed to be capable of withstanding continuous operating temperatures of 103°C (217°F). Formulated to offer improved resistance to cathodic disbondment and excellent corrosion resistanceHigh Tg.

7-2555–  used in submerged or wet conditions where high in-service temperatures exist, up to 155°C (311°F)



Dual Layer Systems

7-2610- Abrasion resistant overcoat (ARO) provided abrasion an impact resitance, aids in protecting the the corrosion coating from damage during the installation or directional drilling process.

7-2504- Provides water and impact resistance at high temperatures, capable of withstanding continuous operating temperatures of 130°C (265°F).

7-2502NS- Provides a bonded, non-slip surface over standard FBE. This coating provides additional shear slip resistance to concrete coated pipe, used for negative buoyancy in offshore installations. (NS is a sacrificial coating and can be applied over any of our systems.

7-2675- When used with 7-2555, the operating systems increases to 180°C (356°F). The second layer provides reduced water permeability and improved chemical resistance.

Nap-Gard® Internal Pipe Coatings

These coatings are used for a variety of internal corrosion protection from drinking water pipes to pipes/tubing in the most stringent down hole environments:

7-0008- Capable of withstanding continuous operating temperatures of 93°C (200°F).

7-0017- Capable of withstanding continuous operating temperatures of 140°C (285°F). Provides corrosion protection in high temperature and high pressure sweet and sour gas environments.

7-0014 -Designed for both external and internal pipe coating for buried pipeline service.  In particular, it is recommended for use on the inside of steel pipe. Meets the requirements of AWWA standards C116, C213, C550 and CSA standard Z245.20-10. Certified to NSF-61, drinking water system components.


FBE Rebar, Valve, Girth Weld & Repair

Liquid


Technical Data Sheets


Type Title Date Filesize
Type Title Date Filesize

    Nap-Gard 7-0010 TDS.pdf
28-Oct-2022
(PDF 186.9 kB)
28-Oct-2022
(PDF 186.9 kB)

    Nap-Gard 7-1861 TDS.pdf
28-Oct-2022
(PDF 116.1 kB)
28-Oct-2022
(PDF 116.1 kB)

    Nap-Gard 7-1862 TDS.pdf
28-Oct-2022
(PDF 115.5 kB)
28-Oct-2022
(PDF 115.5 kB)

    Nap-Gard 7-1868 TDS.pdf
28-Oct-2022
(PDF 159.8 kB)
28-Oct-2022
(PDF 159.8 kB)

    Nap-Gard 7-2500 Series TDS.pdf
28-Oct-2022
(PDF 203.7 kB)
28-Oct-2022
(PDF 203.7 kB)

    Nap-Gard 7-2502NS Series TDS.pdf
28-Oct-2022
(PDF 557.2 kB)
28-Oct-2022
(PDF 557.2 kB)

    Nap-Gard 7-2504 TDS.pdf
28-Oct-2022
(PDF 214.0 kB)
28-Oct-2022
(PDF 214.0 kB)

    Nap-Gard 7-2514EN Series TDS.pdf
28-Oct-2022
(PDF 195.6 kB)
28-Oct-2022
(PDF 195.6 kB)

    Nap-Gard 7-2525 TDS.pdf
28-Oct-2022
(PDF 256.1 kB)
28-Oct-2022
(PDF 256.1 kB)

    Nap-Gard 7-2534 TDS.pdf
28-Oct-2022
(PDF 190.8 kB)
28-Oct-2022
(PDF 190.8 kB)

    Nap-Gard 7-2555 TDS.pdf
28-Oct-2022
(PDF 245.0 kB)
28-Oct-2022
(PDF 245.0 kB)

    Nap-Gard 7-2732P and 7-2732PLG TDS.pdf
28-Oct-2022
(PDF 145.7 kB)
28-Oct-2022
(PDF 145.7 kB)

    Nap-Gard 7-2815FG TDS.pdf
28-Oct-2022
(PDF 138.7 kB)
28-Oct-2022
(PDF 138.7 kB)

    Nap-Gard 7-3500T TDS.pdf
28-Oct-2022
(PDF 184.7 kB)
28-Oct-2022
(PDF 184.7 kB)

    Nap-Gard 7-4510 TDS.pdf
28-Oct-2022
(PDF 186.3 kB)
28-Oct-2022
(PDF 186.3 kB)

    Sol-Gard PCW601S9 TDS.pdf
28-Oct-2022
(PDF 158.9 kB)
28-Oct-2022
(PDF 158.9 kB)

    Nap-Gard 7-0015 TDS.pdf
28-Oct-2022
(PDF 204.8 kB)
28-Oct-2022
(PDF 204.8 kB)

    Nap-Gard 7-0017HT TDS.pdf
28-Oct-2022
(PDF 250.9 kB)
28-Oct-2022
(PDF 250.9 kB)

    Nap-Gard 7-1631S TDS.pdf
28-Oct-2022
(PDF 120.5 kB)
28-Oct-2022
(PDF 120.5 kB)

    Nap-Gard 7-1808 TDS.pdf
28-Oct-2022
(PDF 131.7 kB)
28-Oct-2022
(PDF 131.7 kB)

    Nap-Gard 7-2610 TDS.pdf
15-Mar-2023
(PDF 226.1 kB)
15-Mar-2023
(PDF 226.1 kB)

Application Procedures


Type Title Date Filesize
Type Title Date Filesize

    Nap-Gard_Gold_Dual.pdf
28-Oct-2022
(PDF 327.2 kB)
28-Oct-2022
(PDF 327.2 kB)

    Nap-Gard_Gold_Field_Girth_Weld.pdf
28-Oct-2022
(PDF 247.0 kB)
28-Oct-2022
(PDF 247.0 kB)

    Nap-Gard_Nap-Rock_Field_Girth_Weld_FBE_Dual.pdf
28-Oct-2022
(PDF 247.1 kB)
28-Oct-2022
(PDF 247.1 kB)

    Nap-Gard_Non_Slip_Dual_Powder.pdf
28-Oct-2022
(PDF 334.3 kB)
28-Oct-2022
(PDF 334.3 kB)

28-Oct-2022
(PDF 333.3 kB)

    Nap-Gard_Single_Layer.pdf
28-Oct-2022
(PDF 320.3 kB)
28-Oct-2022
(PDF 320.3 kB)

    Nap-Gard_Sol-Gard.pdf
28-Oct-2022
(PDF 328.2 kB)
28-Oct-2022
(PDF 328.2 kB)

    7-0008__Internal_Pipe_Coating.pdf
28-Oct-2022
(PDF 256.2 kB)
28-Oct-2022
(PDF 256.2 kB)

    7-0010_Internal_Pipe_Coating.pdf
28-Oct-2022
(PDF 255.6 kB)
28-Oct-2022
(PDF 255.6 kB)

    7-0017 -Black_Beauty_FBE.pdf
28-Oct-2022
(PDF 254.5 kB)
28-Oct-2022
(PDF 254.5 kB)

    Nap-Gard_Field_Girth_Weld_FBE.pdf
28-Oct-2022
(PDF 246.2 kB)
28-Oct-2022
(PDF 246.2 kB)

CSA


Type Title Date Filesize
Type Title Date Filesize

    72500 Series CSA.pdf
12-Sep-2018
(PDF 452.2 kB)
12-Sep-2018
(PDF 452.2 kB)

    72514LGEN CSA 2017.pdf
12-Sep-2018
(PDF 1.4 MB)
12-Sep-2018
(PDF 1.4 MB)

    CSA 72504 with 72508 Cert 2017.pdf
12-Sep-2018
(PDF 520.4 kB)
12-Sep-2018
(PDF 520.4 kB)

    CSA 7-2504 cert-2017.pdf
12-Sep-2018
(PDF 811.3 kB)
12-Sep-2018
(PDF 811.3 kB)

    72555 CSA 2017.pdf
12-Sep-2018
(PDF 1.5 MB)
12-Sep-2018
(PDF 1.5 MB)

    CSA 72610.pdf
12-Sep-2018
(PDF 738.5 kB)
12-Sep-2018
(PDF 738.5 kB)
